Schema Types

  • Star Schema.

  • Snowflake Schema.

Star Schema

Star Schema Main Characteristics

  • Simplicity: It is the simplest type of DWH schemas.

  • Query effectiveness: Because of simplicity, It needs less join to query the data (It is optimized to query large dataset).

  • Data Redundancy and Large Table Size: Due to de-normalization, it has a data redundancy, and the table size is huge.

  • Most used and widely supported.

Star Schema Characteristics

  • Dimensions represented by one one-dimension table.

  • The dimension table are not joined to each other

  • The fact table would contain key and measure.

  • Data integrity is not enforced due to the de-normalized structure.

Schema Types: Star Schema Example

Star Schema Example

What is Snowflake?

Snowflake Photo taken from https://earthsky.org

Real Snowflake Photo taken from [https://earthsky.org]

Snowflake Simple Design

Snowflake Simple Design

Snowflake Final Design

Snowflake Final (Complex) Design

Snowflake Schema Characteristics

  • Extension: Snowflake is an extension of the Star Schema.

  • Normalized: Dimension tables are normalized; this means every dimension may expand into additional tables.

  • Disk Space Efficiency: Due to its normalization methodology, it uses less desk space, which enhances the query as we scan less data size.

  • Complicated: Due to the normalization query needs to join more table in some cases to get the data which reduces the performance.

Schema Types: Snowflake schema (Example)

Snowflake Schema Example

Star Vs Snowflake Schema

Star Snowflake
Dimension represented by one-table Dimension tables are expanded into multi-tables
Fact table surrounded by dimension tables Fact table surrounded by Hierarchy of dimension tables
Less join Requires many joins
Simple Design Very Complex Design
De-normalized Data structure Normalized Data Structure
High level of Data redundancy Very low-level data redundancy
Maintenance is difficult Maintenance is easier
Good for datamarts with simple relationships (1:1 or 1:many) Good for core to simplify (many:many)
