Multi Valued Dimension

Lesson Notes

Shrunken Rollup Changing Dimension Lesson Notes:

1. Presentation Mode
2. Static Mode

Video

Multi-valued dimensions

• When the relationships between the dimension member and the fact are many to many which means the dimension members are lower granularity than the facts.

• Fact table should contains one-to-one relationship with the dimension. So, we introduce the Bridge table when we need to related multiple dimensions values with one record.

Multi-valued dimensions Examples

• Patients can have multiple diagnoses.

• Students can have multiple majors.

• customers can have multiple account.

• Authors can have multiple publications.

Multi-valued dimensions Article Sales Example

• Assume we need to report the sales of article and we have some articles has more than one author.

• Each author has weighting factor for each article.

• According to the report we need to check each author and associate with the articles they have authored. How can we model this case?

• Assume the first article has only one author Moustafa, and the second article has two authors Ahmed & Amr.

Implementation 1

Multi-valued dimensions (Implementation-1)

What are the problems in this implementation?

• We can’t get the weighting factor for each author.

• Duplicated rows in sales.

Implementation 2

Multi-valued dimensions (Implementation-2)

Final Implementation

Example Reference

• Example in this video taken from this link https://www.nuwavesolutions.com/bridge-tables/

Further Reading

Dimensional Modeling: In a Business Intelligence Environment. The book is free, and you can download it from this link. You can read the following:

• Chapter 6.3.10 Multi-valued dimensions page 288
• Chapter 6.3.11 Use of bridge tables page 291
